Rangkaian ini menggunakan PIC16F84A yang sangat mudah didapatkan di toko elektronik. Biasanya harganya berkisaran antara 30.000 rupiah sampai 40.000 rupiah. Rangkaian alarm ini menggunkan 4 seven segment display dengan common anode maupun katode sesuai dengan programnya. Rangkaian ini juga menggunakan kristal 16Mhz yang sangat mudah juga didapat di toko elektronik. Rangkaian alarm ini dapat diatur kapan akan berbunyi melaui tombol/button yang ada pada rangkaian maupun langsung dimasukkan kedalam program. Rangkaian ini juga dilenkapi dengan 3 tombol/button yaitu tombol up, down, dan select. Anda dapat memprogram hari minggu, jam, menit dan durasi alarm. Jumlah alarm hanya dibatasi ruang ROM saja. Dan inilah skemanya!
Dan inilah daftar komponen yang dibutuhkan :
- PIC16F84A x1
- Resistor 1k x7
- Transistor BC547 x4
- 7- segment display x4
- Capasitor 27pF x2
- Capasitor 100nF x1
- Push button x3
- Resistor 330ohm x7
- X-Tal 16Mhz x1
'******************************************************************************
' PIC16F84A ALARM CLOCK
'******************************************************************************
'
' feel free to use this code at your own risks
'
' target : PIC16F84A, 16 Mhz crystal
' HS clock, no watchdog.
'
' Author : Bruno Gavand, September 2007
' see more details on http://www.micro-examples.com/
'
'******************************************************************************
program alarmClock
'
' if you are using COMMON CATHODE LED display, uncomment this definition.
' if you are using COMMON ANODE LED display, comment this definition.
'
'#define CATHODE_COMMUNE
symbol LUNDI = 0 ' monday
symbol MARDI = 1 ' thuesday
symbol MERCREDI = 2 ' wednesday
symbol JEUDI = 3 ' thursday
symbol VENDREDI = 4 ' friday
symbol SAMEDI = 5 ' saturday
symbol DIMANCHE = 6 ' sunday
symbol LMMJV = 7 ' from monday to friday included
'
' alarm definitions, to be changed on your needs
'
symbol NBALARM = 16 ' number of programmed alarms
const alarmTable as byte[NBALARM * 4] = (
' JOUR HEURE MINUTE DUREE (secondes, 59 maxi)
' DAY HOUR MINUTE DURATION (in seconds, max is 59)
LUNDI, 8, 30, 10,
LUNDI, 12, 30, 10,
LUNDI, 14, 00, 10,
LUNDI, 16, 30, 10,
MARDI, 8, 30, 10,
MARDI, 12, 30, 10,
MARDI, 14, 00, 10,
MARDI, 16, 30, 10,
JEUDI, 8, 30, 10,
JEUDI, 12, 30, 10,
JEUDI, 14, 00, 10,
JEUDI, 16, 30, 10,
VENDREDI, 8, 30, 10,
VENDREDI, 12, 30, 10,
VENDREDI, 14, 00, 10,
VENDREDI, 16, 30, 10
)
dim maxcount as word ' number of TMR0 overflow per second
dim scaler as word ' RTC scaler
dim jj as byte ' day of week, 0 is monday
dim hh as byte ' hour
dim mn as byte ' min
dim ss as byte ' sec
dim digiled as byte[4] ' 4 x 7 segment table
dim digit as byte ' number of current digit to be displayed
dim dp as byte ' decimal point
dim key as byte ' key code
dim alarm as byte ' alarm flag
'
' the ISR works as real time clock
'
sub procedure interrupt
dim i as byte
'
' count time
'
scaler = scaler + 1
if scaler > maxcount
then
scaler = 0
inc(ss)
if ss = 60
then
ss = 0
inc(mn)
if mn = 60
then
mn = 0
inc(hh)
if hh = 24
then
hh = 0
inc(jj)
if jj = 8
then
jj = 1
end if
end if
end if
end if
end if
'
' LED display
'
#ifdef CATHODE_COMMUNE
PORTA = PORTA and $f0
TRISA = $0f
key = PORTA
TRISA = 0
PORTB = 0
#else
PORTA = PORTA or $0f
TRISA = $0f
key = PORTA
key = not(key)
TRISA = 0
PORTB = $ff
#endif
key = key and $07
digit = digit + 1
if digit > 3
then
digit = 0
i = $01
else
i = $01 << digit
end if
#ifdef CATHODE_COMMUNE
PORTB = digiled[digit]
PORTA = PORTA or i
#else
PORTB = digiled[digit]
PORTB = not(PORTB)
PORTA = PORTA and not(i)
#endif
INTCON.T0IF = 0
end sub
'
' converts digit to 7 segment
'
sub function intTo7seg(dim n as byte) as byte
select case n
case 0 result = $3F
case 1 result = $06
case 2 result = $5B
case 3 result = $4F
case 4 result = $66
case 5 result = $6D
case 6 result = $7D
case 7 result = $07
case 8 result = $7F
case 9 result = $6F
end select
end sub
'
' select a value with keys
' value is pointed to by v, display char s as header, maximum value is max
'
sub procedure setValue(dim v as ^byte, dim s as byte, dim max as byte)
digiled[0] = s
digiled[1] = 0
while 1
if key.0
then
inc(v^)
if(v^ > max)
then
v^ = 0
end if
end if
if key.1
then
if(v^ = 0)
then
v^ = max
else
dec(v^)
end if
end if
if key.2
then
Delay_ms(50)
while key.2
wend
Delay_ms(50)
scaler = 0
ss = 0
return
end if
digiled[2] = intTo7seg(v^ / 10)
digiled[3] = intTo7seg(v^ mod 10)
delay_ms(300)
wend
end sub
'
' program entry
'
main:
dim i as byte
'
' init variables
'
dp = 0
hh = 0
mn = 0
ss = 0
jj = 0
maxcount = 15625
'
' init I/O
'
PORTA = 010000
TRISA = 000000
PORTB = 0
TRISB = $00
'
' init interrupts
'
INTCON = %10100000
OPTION_REG = %11011000
Delay_ms(50)
'
' clock adjustment
'
setValue(@hh, 116, 23)
setValue(@mn, 55, 59)
setValue(@jj, 14, 6)
'
' forever loop
'
while true
if key
then
'
' display day and seconds (what for ? don't remember !)
'
digiled[0] = intTo7seg(jj)
digiled[1] = 0
digiled[2] = intTo7seg(ss / 10)
digiled[3] = intTo7seg(ss mod 10)
else
'
' display hours and minutes
'
if hh < 10
then
digiled[0] = 0
digiled[1] = intTo7seg(hh)
else
digiled[0] = intTo7seg(hh / 10)
digiled[1] = intTo7seg(hh mod 10)
end if
digiled[2] = intTo7seg(mn / 10)
digiled[3] = intTo7seg(mn mod 10)
end if
'
' blinks semicolon (or decimal point)
'
if scaler > maxcount / 2
then
dp.1 = 1
else
dp.1 = 0
end if
'
' set decimal points
'
digiled[0].7 = dp.0
digiled[1].7 = dp.1
digiled[2].7 = dp.2
digiled[3].7 = dp.3
'
' check for alarm condition
'
alarm = 0
for i = 0 to (NBALARM - 1) * 4
if ((alarmTable[i] = jj) or ((alarmTable[i] = LMMJV) and (jj < SAMEDI)))
and (alarmTable[i + 1] = hh)
and (alarmTable[i + 2] = mn)
and (alarmTable[i + 3] > ss)
then
inc(alarm)
end if
next i
if alarm
then
'
' set alarm
'
dp.3 = 1
PORTA.4 = 0
else
'
' clear alarm
'
dp.3 = 0
PORTA.4 = 1
end if
wend
end.
